About Schmid

Schmid Schrauben is an Austrian pioneer in timber construction fasteners, with a history dating back to 1842. Headquartered in Hainfeld, the company has evolved into one of Europe’s leading manufacturers of high-performance screws for structural timber applications. With a strong focus on quality, innovation, and sustainability, Schmid supports timber construction at every scale—from traditional wood framing to advanced CLT and glulam structures.

Schmid’s flagship RAPID® screw series are engineered specifically for high-strength timber connections. Their products are available in various lengths and coatings, which reduce friction, improve battery efficiency, and enhance corrosion protection.

With nearly two centuries of experience and a focus on timber innovation, Schmid Schrauben remains a trusted partner for engineers and builders looking for reliable, certified fastening solutions in modern wood construction.

Schmid Platform Updates

Recent Product Updates

The Fastest Growing Platform for Timber Specification

Release 2.5.0 – Half-lap and Spline joints

Release 2.5.0 – Half-lap and Spline joints

Release 2.4.0 – New Fire Module Is Here

Release 2.4.0 – New Fire Module Is Here

Release 2.1.10 New Composite Systems: Timber-Concrete Composites & Ribbed Deck Calculators.

Release 2.1.10 New Composite Systems: Timber-Concrete Composites & Ribbed Deck Calculators.

Release 2.1.1 – CLT to Steel Beam Connection Details, Dowel/Bolt Updates, Screw Filtering & More!

Release 2.1.1 – CLT to Steel Beam Connection Details, Dowel/Bolt Updates, Screw Filtering & More!

Release 2.1.2- USA and Canada Beta Version

Release 2.1.2- USA and Canada Beta Version

Release 2.1.3 – Focus on Perpendicular to Grain Compression

Release 2.1.3 – Focus on Perpendicular to Grain Compression

Release 2.1.4 – Fire Design!

Release 2.1.4 – Fire Design!

Release 2.1.5 – New Bracket Calculator Category

Release 2.1.5 – New Bracket Calculator Category

Release 2.1.6 – Major Updates & New National Annexes

Release 2.1.6 – Major Updates & New National Annexes

Release 2.1.7 – Screw Connections

Release 2.1.7 – Screw Connections

Release 2.1.8 – Analysis & One Page Summaries!

Release 2.1.8 – Analysis & One Page Summaries!

SPEC Toolbox Release!

SPEC Toolbox Release!

Products Integrated

Explore the Schmid Integrated System with SPEX Toolbox, a game-changing solution for modern construction that boosts efficiency and precision. Its intuitive interface allows architects and builders to seamlessly integrate Schmid products for enhanced performance and sustainability.

ScrewsScrews
Screw Family Thread Type Head Type Diameter Length Service Class Specification
RAPID® CS Partially Threaded countersunk head (milling pocket) 4 mm 30-50 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® CS Partially Threaded countersunk head (milling pocket) 4,5 mm 30-80 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® CS Partially Threaded countersunk head (milling pocket) 5 mm 30-120 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® CS Partially Threaded countersunk head (milling pocket) 6 mm 50-300 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® CS Partially Threaded countersunk head (milling pocket) 8 mm 80-500 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® CS Partially Threaded countersunk head (milling rips) 10 mm 80-500 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® CS Partially Threaded countersunk head (milling rips) 12 mm 100-400 mm SC1, SC2 Carbon steel, friction part, single thread, ridged core, YellWin 500+
RAPID® WH Partially Threaded washer head 6 mm 60-300 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® WH Partially Threaded washer head 8 mm 80-500 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® WH Partially Threaded washer head 10 mm 100-500 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, YellWin 500+
RAPID® DUAL Partially Threaded dual head 8 mm 50-400 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, BlueWin
RAPID® DUAL Partially Threaded dual head 10 mm 60-400 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, BlueWin
RAPID® DUAL Partially Threaded dual head 12 mm 80-400 mm SC1, SC2 Carbon steel, friction part, single thread, ridged core, BlueWin
RAPID® SSF Partially Threaded SuperSenkFix head 6 mm 80-200 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, BlueWin 700+
RAPID® SSF Partially Threaded SuperSenkFix head 8 mm 80-400 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, BlueWin 700+
RAPID® SSF Partially Threaded SuperSenkFix head 10 mm 120-400 mm SC1, SC2 Carbon steel, friction part, HiLo-thread, ridged core, BlueWin 700+
RAPID® FT CS Fully Threaded countersunk head (milling rips) 8 mm 120-600 mm SC1, SC2 Carbon steel, single thread, compressor, half-tip (HSP), YellWin 500+
RAPID® FT CS Fully Threaded countersunk head (milling rips) 10 mm 120-1000 mm SC1, SC2 Carbon steel, single thread, compressor, half-tip (HSP), YellWin 500+
RAPID® FT CS Fully Threaded countersunk head (milling rips) 12 mm 200-1000 mm SC1, SC2 Carbon steel, single thread, compressor, half-tip (HSP), YellWin 500+
RAPID® FT CL Fully Threaded cylinder head 6 mm 80-200 mm SC1, SC2 Carbon steel, single thread, compressor, full-tip, YellWin 500+
RAPID® FT CL Fully Threaded cylinder head 8 mm 120-400 mm SC1, SC2 Carbon steel, single thread, compressor, full-tip, YellWin 500+
RAPID® FT CL Fully Threaded cylinder head 8 mm 450-600 mm SC1, SC2 Carbon steel, single thread, compressor, half-tip (HSP), YellWin 500+
RAPID® FT CL Fully Threaded cylinder head 10 mm 200-1000 mm SC1, SC2 Carbon steel, single thread, compressor, half-tip (HSP), YellWin 500+
RAPID® T-LIFT Fully Threaded dual head 12 mm 60-380 mm SC1, SC2 Carbon steel, single thread, compressor, full-tip, BlueWin
RAPID® T-LIFT Fully Threaded dual head 16 mm 180-600 mm SC1, SC2 Carbon steel, single thread, compressor, full-tip, BlueWin
RAPID® Hardwood CS Partially Threaded countersunk head (milling pocket) 8 mm 80-440 mm SC1, SC2 Carbon steel, friction part, single thread, compressor, BlueWin 700+
RAPID® Hardwood WH Partially Threaded washer head 8 mm 160 mm SC1, SC2 Carbon steel, friction part, single thread, compressor, BlueWin 700+
